ELEPHANT G-5 รอกวิ่ง 5 TON มีเกียร์
• รอกวิ่งบนราง I-BEAM ตราช้าง รุ่นมีเกียร์ (ญี่ปุ่น)
• รุ่น G-5 ความสามารถยก Capacity (ton) 5 t
• สามารถปรับได้ตามความกว้างของบีมในสามขั้นตอน ออกแบบให้ใช้กับงานหนัก มีความแข็งแกร่งทนทาน
• ล้อรอกวิ่งพอดีกับทั้ง i-beam และ H-beam
• ตลับลูกปืนคุณภาพสูงที่ใช้ในรอกช่วยให้การเคลื่อนที่ของล้อเป็นไปอย่างราบรื่น
• สินค้า จากญี่ปุ่น
รหัสสินค้า: E021-0550
หมวดหมู่: รอกวิ่งบนราง แบบธรรมดา แบบเกียร์
Product Description
รอกวิ่งบนราง ตราช้าง ชนิดมีเกียร์ 5 ตัน
• G SERIES
Model : E021-0550
Specifications ข้อมูลจำเพาะ
• ความสามารถ Capacity : 5.0 ton
• ความกว้าง I-Beam :
– No Collars :125
– With 2 Collars : 150 mm
– With 4Collars : 175 mm
• ความสูง (H) I-Beam : 250 – 450
• Min.Radius of I-Beam ขีดต่ำสุดรัศมีรอบหมุน (mm) : 2300
• ขนาดโซ่ Diameter X pitch of Hand Chain : 6 x 3.0 mm
• น้ำหนัก Net weight : 55.8 kg
Dimensions (mm)

รายละเอียดรุ่น อื่นฯ
[table id=602 /]
| • To any beam width : Elephant adjustable trolleys are adjustable to any by beam width, in three stages, simply by increasing or decreasing the number of the adjusting collars. |
| • For both I-beam and H-beam : Wheels of the trolley fit both i-beam and H-beam. |
| • High quality closed bearings : High quality closed bearings employed in the trolley provide smooth wheel traveling. |
| น้ำหนัก | 57.9 kg |
|---|
